Network recorders · Product spotlight
Reolink RLN8-410: build a local recording system
A diskless recorder for compatible Reolink cameras, with eight PoE ports and revision-dependent expansion.
Researched
Researched buying guide
For compatible cameras with local storage
Reolink RLN8-410 · diskless
One black RLN8-410 NHD recorder, adapter, HDMI cable, mouse, 1m network cable and guide. No HDD or cameras included.
Check it out: Reolink RLN8-410 on Amazon.de (opens a new tab)- PoE camera ports
- 8 × 10/100 Ethernet
- Installed storage
- None; hard drive purchased separately
- Display outputs
- HDMI up to 3840 × 2160; VGA up to 1920 × 1080
Affiliate links may earn us a commission. Check the exact variant and current price. Specifications are manufacturer claims, not our own test results.
Choose storage before recording
The linked package is diskless. Add a compatible surveillance hard drive and suitable cameras before expecting a complete recording system. Local recording can keep footage on your own hardware, but it still needs a sensible retention plan and periodic checks that recording actually works. Place the recorder where cables reach comfortably and ventilation remains clear, with a monitor available for initial setup.
Match the hardware revision
RLN8-410 has existed in several revisions. Current N7MB01 documentation allows larger drives and newer camera combinations than older versions, while the checked listing does not guarantee a hardware number. Confirm the delivered revision in system information before ordering expansion storage. Applying a current specification to every older RLN8-410 would give the wrong capacity and compatibility expectations.
Count cameras, not just sockets
Eight PoE sockets do not mean every supported configuration is limited to eight entries. Current N7MB01 guidance allows eight wired-powered cameras plus four supported battery Wi-Fi cameras, or twelve supported battery cameras. Model and firmware support still matter, and battery-camera behaviour is not automatically continuous recording. Check the recorder’s supported-device list for each exact camera you intend to connect.
Plan the network and display
The current specification lists 10/100 networking, HDMI output up to 4K and a separate VGA connection. Recording a high-resolution stream does not mean every view is displayed or replayed at that resolution simultaneously. Use the PoE rating of each camera when planning power, rather than multiplying the maximum port figure into an assumed system budget. Remote viewing also needs a working network connection.
Make expansion a checked decision
This is useful for a compatible Reolink installation where choosing and maintaining local storage is welcome. It is less suitable when you want a complete camera-and-drive kit or guaranteed support for unrelated cameras. Keep important clips separately before recordings cycle out, and confirm the storage limit for your revision. The table distinguishes the current manufacturer specification from the older hardware that shares this product name.
Technical details
Specifications and compatibility.
| Specification | Details |
|---|---|
| Linked version | RLN8-410 NHD, diskless, black; B0GSVGVQH6 |
| PoE camera ports | 8 × 10/100 Ethernet |
| Installed storage | None; hard drive purchased separately |
| Display outputs | HDMI up to 3840 × 2160; VGA up to 1920 × 1080 |
| Hardware scope | Current manufacturer specifications describe N7MB01; delivered revision is not fixed by the checked listing |
| Camera count, N7MB01 | Up to 8 wired-powered plus 4 supported battery Wi-Fi cameras, or 12 supported battery Wi-Fi cameras |
| Battery camera support | Specific models and suitable NVR/camera firmware required; not all battery cameras work |
| Recording resolution | Current N7MB01: up to 16MP supported cameras; camera/model-dependent |
| Compression | H.264 / H.265 |
| Local playback | Four channels synchronously, per current specification |
| Drive interfaces | One internal SATA and one external eSATA |
| N7MB01 storage limit | Up to 8TB per drive / 16TB total; compatible drives required |
| Older storage limits | H3MB18/N2MB02/N3MB01: 6TB each; H3MB16/H3MB02: 4TB each |
| LAN uplink | One 10/100 Ethernet port; not gigabit |
| PoE standard / port power | IEEE 802.3af/at; up to 25W per port; shared system budget not established |
| Other ports | Two USB 2.0; RCA audio output |
| Power | 48–53V DC; under 10W excluding HDD and PoE loads |
| Dimensions / weight | 260 × 41 × 230mm; approximately 1.4kg |
| Operating environment | −10°C to 45°C; 10–90% humidity |
| Access | Local monitor/mouse or supported app/client; remote access requires network/internet setup |
| Current user / stream limits | 20 users: one administrator and 19 others; up to 12 streams, 10 substreams and 2 main streams |
| Camera checks | Verify the recorder’s Supported Devices list; ONVIF wording alone does not establish full compatibility |
| Package | Recorder, power adapter, HDMI cable, mouse, 1m network cable and guide; no HDD or cameras |
The final check
A good fit if…
You want local recording from compatible Reolink cameras and can select the drive, configure the system and verify its revision.
Keep in mind
No cameras or HDD included. Drive limits, battery-camera support and firmware requirements vary by hardware revision.
